Tesnit® BA-50
Product Description
Gasket Material with Good Mechanical and Chemical Properties
TESNIT® BA-50 is a special gasket material based on aramid fiber and NBR. The gasket material TESNIT® BA-50 has excellent chemical and dynamic resistance. It has a wide range of applications. It is used in the gas, food, and chemical industries.
show more...
Application Areas
For low-level loads;
Water
Gas
Oil
It is a gasket material resistant to fuel.
Surface Treatment: If desired, the surface of the gasket material is subjected to graphite, PTFE, and antistatic coating processes.
show more...
Main Components
Aramid fiber, NBR
Approval: DVGW 3535/6, DVGW KTW, DVGW W270, CRS, Germanischer Lloyd,
TA LUFT (VDI 2440), TARC/MRPRA, WRAS/WQc
show more...
Standard Sheet Dimensions
Width x Height (mm): 1000 x 1500 | 1500 x 1500 | 3000 x 1500 | 4500 x 1500
Thickness (mm): 0.5 | 0.8 | 1.0 | 1.5 | 2.0 | 3.0
show more...
* Other sizes and thicknesses can be accommodated upon request.
General application area, provided that chemical compatibility conditions and known installation principles are applied.
Maximum performance is ensured by adhering to the appropriate technical values in connection design and gasket installation. It is recommended to seek consultancy services.
Limited application area. Technical consultancy is mandatory.
In a known application, the best method to determine gasket compatibility is by using the P-T diagram. The highest values of P-T can be misleading. Maximum temperature and maximum pressure should not be used simultaneously. Maximum values are provided purely for indicative purposes. These values are related both to the gasket material properties and to the operating conditions. It is recommended to use the P-T diagram when selecting a gasket.
